Processor
Intel® Core™ i7-14650HX, 16C (8P + 8E) / 24T, P-core 2.2 / 5.2GHz, E-core 1.6 / 3.7GHz, 30MB
Graphics
NVIDIA® GeForce RTX™ 4060 8GB GDDR6, Boost Clock 2370MHz, TGP 140W, 233 AI TOPS
Chipset
Intel HM770 Chipset
Memory
1x 16GB SO-DIMM DDR5-5600
Memory Slots
Two DDR5 SO-DIMM slots, dual-channel capable
Max Memory
Up to 96GB DDR5-5600
Storage
1TB SSD M.2 2280 PCIe® 4.0x4 NVMe®
Storage Slot
Two M.2 2280 PCIe® 4.0 x4 slots
Card Reader
microSD Card Reader
Audio Chip
High Definition (HD) Audio, Realtek® ALC3287 codec
Speakers
Stereo speakers, 2W x2, optimized with Nahimic Audio
Camera
FHD 1080p with E-shutter
Power Adapter
230W Slim Tip (3-pin)
Special Features
AI Chip: LA1
Display
16" WQXGA (2560x1600) IPS 500nits Anti-glare, 100% sRGB, 240Hz, DisplayHDR™ 400, Dolby Vision®, G-SYNC®, Low Blue Light
Color Calibration
Factory Color Calibration
Keyboard
4-Zone RGB Backlit, Thai
Touchpad
Buttonless Mylar® surface multi-touch touchpad, 75 x 120 mm (2.95 x 4.72 inches)
Case Material
Aluminium (Top), PC-ABS (Bottom)
Weight
Around 2.36 kg (5.2 lbs)
Operating System
Windows 11 Home Single Language, English
Ethernet
100/1000M (RJ-45)
WLAN + Bluetooth
Wi-Fi 6E, 11ax 2x2 + BT5.2
Security Chip
Firmware TPM 2.0 Enabled
Warranty
3Y ADP (Accidental Damage Protection), 3Y Legion Ultimate Support เบอร์โทร เบอร์โทร On-site service +66 2028-1508, 1800 012 251
Green Certifications
ErP Lot 6/26, RoHS compliant
Other Certifications
TÜV Rheinland® Low Blue Light (Hardware Solution)
Size
359.7 x 25.2 x 262.3 mm
